ORALITE® 5600
Fleet Engineer Grade

ORALITE® 5600 Fleet Engineer Grade is a rough, weather and solvent resistant product which unifies high flexibility and excellent corrosion resistance. The material can be cut to size in the plotter and has been specially designed for demanding commercial applications and fleet decorations to create lettering, markings and decorations. It is designed for applications where a decommissioning is possible. Because of a special PVC cast structure the material can also be attached on moderately curved surfaces with rivets or corrugated substrates. ORALITE® 5600 consists of catadioptric glass beads that are attached to a transparent plastic material layer (design A, previously type I).
  • Reflective film with cast PVC surface, structure A, reflective values comparable to RA1
  • Available in 11 colors, film thickness without protective paper 0.150mm
  • Highly flexible film: Adapts perfectly to beads and rivets
  • Removable under the influence of heat
  • No edge sealing required
  • Long-term use: Expected service life of up to 7 years when used correctly

Product information

Technical properties

Resistance

Durability 7 Year(s) with professional processing, with vertical outdoor weathering, central European normal climate
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Elongation at break Minimum elongation at break along: 100 %
Minimum elongation at break across: 100 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 0 MPa
Minimum tensile strength across: 0 MPa
Temperature resistance Minimum temperature: -50 °C
Maximum temperature: 95 °C 		bonded to aluminum, normal Central European climate

Adhesive properties

Removability Removable The use of heat helps with easily removing the product.
Adhesive power 15 N/25 mm after 24 h, adhered on stainless steel | Average value, FINAT TM 1
16 N/25 mm after 24 h, adhered on acrylic varnish | Average value, FINAT TM 1
Processing
Recommended printing procedure Screen printing, Digital printing with solvent-based inks, UV printing, Latex printing
Application temperature Minimum temperature 10 °C
Proposed application technology Dry application
Product Construction
Liner Liner: Silicone cardboard PE coated on both sides
Surface weight: 145 g/m²
Adhesive Solvent-polyacrylate

General

Thickness 0.15 mm Average value, without protective paper
Reflective Characteristics
Reflective Technology Glass bead
Reflectivity Compliance Reflective film structure: Design A
Reflectivity classes: RA1
Dimensions
Format Roll
Standard width 610 mm
1235 mm
760 mm only available in white
1370 mm only available in white
1520 mm only available in white
Standard length 25 m
50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
