ORAGUARD® 290
Laminating Film

3D adhesive, cast premium PVC laminating film with high dimensional stability and highly effective UV protection. Suitable for long-term outdoor applications.

Product information

Technical properties

Resistance

Durability Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.543
8 Year(s)
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Resistance to solvents and chemicals Water, Cleaning agent, Alcohol, Aliphatic solvents at room temperature, 72 h after adhesion on aluminium
Maximum shrinkage Maximum shrinkage along 0.1 mm
Maximum shrinkage across 0.1 mm 		bonded to steel | FINAT TM 14
Elongation at break Minimum elongation at break along 120 %
Minimum elongation at break across 120 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 19 N/mm²
Minimum tensile strength across: 19 N/mm² 		EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 60 °C 		adhered on aluminium, central European normal climate

Adhesive properties

Adhesive power 12 N/25 mm after 24 h, on stainless steel | FINAT TM 1, average value
Adhesive Permanent
Processing
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: One-sided siliconized kraft paper
Surface weight: 90 g/m²

General

Thickness 0.05 mm without protective liner and adhesive, average value
Dimensions
Format Roll
Standard width 1050 mm
1370 mm
1520 mm
Standard length 50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
