Technical data sheet - English (EN)
PDF, 91.44kB, 2 Pages
ORAJET® 3951HT
Premium Digital Printing Cast
The premium cast PVC film is available in white and transparent and has a glossy surface. It is suitable for longterm advertising measures, markings and decorations that are to be realized with maximum brilliance and durability in outdoor areas. It is particularly suitable for applications on hard-to-stick surfaces.
Product information
Technical properties
Resistance
| Durability | Durability :with professional processing, with vertical outdoor weathering, central European normal climate | |
|---|---|---|
| 7 Year(s) | White, not printed | |
| 5 Year(s) | Transparent, not printed | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Weak acids, Salts and alkalis, Isopropyl alcohol, Washing suds (0.5 % household cleaner) | At room temperature, 72h adhered to aluminium resistant |
| Maximum shrinkage |
Maximum shrinkage along 0.2 mm
Maximum shrinkage across 0 mm |
Bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along 120 %
Minimum elongation at break across 120 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 N/mm² Minimum tensile strength across: 19 N/mm² |
DIN EN ISO 527 |
| Seawater resistance | no change | adhered on aluminium | after 100 h/23 °C no change, DIN 50021 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 28 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | high tack |
Processing
| Recommended printing procedure | Inkjet printing with latex inks, Inkjet printing with solvent-based inks, Inkjet printing with UV inks |
|---|---|
| Application temperature | Minimum temperature 4 °C |
Product Construction
| Liner |
Liner: One-sided siliconized kraft paper Surface weight: 143 g/m² |
|---|
General
| Thickness | 0.055 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll | |
|---|---|---|
| Standard width | 1520 mm | only available in white |
| 1370 mm | ||
| Standard length | 50 m |
