Technical data sheet - English (EN)
PDF, 170.02kB, 2 Pages
ORALITE® 5200RA
Economy Grade
ORALITE® 5200RA Economy Grade is a reflective film with a thickness of 0.105 mm that has been specially developed for temporary outdoor applications. Thanks to RapidAir® technology, it enables simple and bubble-free application, which makes processing much easier. Available in 6 colours and with a durability of 3 years, it is an ideal solution for temporary outdoor applications.
- Easy to apply: RapidAir® technology ensures bubble-free application
- Versatile application: Suitable for temporary outdoor applications
- Versatile design options: 6 color options and excellent printability for different requirements
- Reliable adhesive: Solvent polyacrylate for permanent adhesion
Available colours
6 Colours
010
White
020
Yellow
035
Orange
030
Red
050
Blue
060
Green
Product information
Technical properties
Resistance
| Durability | 3 day | with professional processing, with vertical outdoor weathering, central European normal climate | no guarantee for non-vertical application |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 82 °C |
adhered on aluminium |
Adhesive properties
| Removability | Removable | |
|---|---|---|
| Adhesive power | 16 N/25 mm | Adhesion after 24 h, on stainless steel | FINAT TM 1 |
| 10 N/25 mm | Adhesion on acrylic coating | FINAT TM 1 | |
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Screen printing, Solvent-based inkjet printing, Eco-solvent printing |
|---|---|
| RapidAir technology | Yes |
| Application temperature | Minimum temperature 15 °C |
| Proposed application technology | Dry application |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 155 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.105 mm | Average value, without protective paper |
|---|
Reflective Characteristics
| Reflective Technology | Glass bead |
|---|---|
| Reflectivity Compliance | Reflective film structure: Aufbau A (eingebette Glaskugeln) |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 610 mm |
| 1235 mm | |
| Standard length | 50 m |
