ORAJET® 3961RA
Caravan Film Premium Cast
Moulded premium PVC film, with excellent adhesive properties on difficult substrates, in white, glossy. The RapidAir technology enables a simple and quick, blister-free adhesion, in particular of large formatted motifs. Air pockets can be easily smoothed out from under the film.
Product information
Technical properties
Resistance
| Durability | 10 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage |
Maximum shrinkage along: 0.2 mm Maximum shrinkage across : 0.2 mm |
Bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium, after 100 h/23 °C no change, DIN 50021 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 20 N/25 mm | after 24 h, on stainless steel | FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent | permanent, with high aggressive initial adhesion and high final adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 4 °C |
Product Construction
| Liner |
Liner: RaidAir paper PE-coated on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.055 mm | without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| 1520 mm | |
| Standard length | 50 m |
