Technical data sheet - English (EN)
PDF, 1.41MB, 2 Pages
ORAJET® 3951RA+
ProSlide™ Premium Digital Printing Cast PVC
Moulded premium PVC film available in white and transparent with glossy surface. Improved repositionability.
Product information
Technical properties
Resistance
| Durability | Durability (general note):Applies for vertical outdoor weathering and central European normal climate. The real durability and durability to be expected depend in particular on ambient conditions, but amongst other things also on | |
|---|---|---|
| 10 Year(s) | with professional processing and proper care and use, white, unprinted | Pre-treatment of the substrate and regular care. Further information is available under: www.orafol.com/gp/europe/de/support | |
| 8 Year(s) | with professional processing and proper care and use, transparent, unprinted | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most |
| Maximum shrinkage |
Maximum shrinkage along: 0.1 mm Maximum shrinkage across : 0.1 mm |
Bonded to steel | FINAT TM 14, average value |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
EN ISO 527, average value |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527, average value |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
Bonded to aluminum, short-term load |
Adhesive properties
| Adhesive power | 14 N/25 mm | after 24 h, on stainless steel | FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner |
Liner: RaidAir paper PE-coated on both sides, siliconised on one side Surface weight: 158 g/m² |
|---|---|
| Front material |
Front material: Premium PVC film Manufacturing process: Moulded |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.055 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1050 mm |
| 1370 mm | |
| 1520 mm | |
| Standard length | 50 m |
