Technical data sheet - English (EN)
PDF, 141.45kB, 2 Pages
ORAJET® 3554
Brick Stone Film
Polymer PVC film, available in white with matt surface.
Product information
Technical properties
Resistance
| Durability | 7 Year(s) | unprinted, with professional processing, with vertical outdoor weathering, central European normal climate |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging (with side holders) vertical storage, at 20 °C and 50 % relative humidity |
| Maximum shrinkage |
Maximum shrinkage along: 0.3 mm Maximum shrinkage across : 0.3 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_transverse_conditon.id.584.409cb8f3 | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_transverse_note.id.584.409cb8f3 |
| Elongation at break |
Minimum elongation at break along: 200 % Minimum elongation at break across: 200 % |
product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_transverse_note.id.584.85d8e904 |
| Tensile strength |
Minimum tensile strength along: 25 MPa Minimum tensile strength across: 25 MPa |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
product.properties.technical_attributes.durability.temperature_resistance_block.temperature_resistance_condition.id.584.16f9c9a1 | product.properties.technical_attributes.durability.temperature_resistance_block.temperature_resistance_note.id.584.16f9c9a1 |
Adhesive properties
| Adhesive power | 24 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value, >25 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.07 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 57.51kB, 2 Pages
Product information - English (EN)
PDF, 140.68kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
