ORAGUARD® 215DU
Laminating Film

Polymer PVC laminating film with highly effective UV protection and reduced silvering when applied to UV-cured printing inks. Suitable for long-term outdoor applications.

Product information

Technical properties

Resistance

Durability Durability :with vertical outdoor exposure, normal Central European climate
5 Year(s)
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50% relative humidity
Resistance to solvents and chemicals Water, Weak acids, Salts and alkalis, Isopropyl alcohol, Washing suds (0.5 % household cleaner) At room temperature
Maximum shrinkage Maximum shrinkage along 0.4 mm
Maximum shrinkage across 0.4 mm 		adhered on aluminium | FINAT TM 14, average value
Elongation at break Minimum elongation at break along 130 %
Minimum elongation at break across 150 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 19 N/mm²
Minimum tensile strength across: 19 N/mm² 		DIN EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 60 °C 		adhered on aluminium, central European normal climate

Adhesive properties

Adhesive power 14 N/25 mm after 24 h, on stainless steel, average value | FINAT TM 1
Adhesive Permanent
Processing
Application temperature Minimum temperature 10 °C
Product Construction
Front material Thickness front material: 0.075 mm
Front material: Polymer PVC film

General

Thickness 0.075 mm without protective liner and adhesive, average value
Dimensions
Format Roll
Standard width 1050 mm only available in glossy and matt
1370 mm only available in glossy and matt
1520 mm only available in glossy and matt
1600 mm only available in glossy and matt
Standard length 50 m

Product videos

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
