Technical data sheet - English (EN)
PDF, 101.21kB, 2 Pages
ORAJET® 3551RA
Polymer PVC film, available in white with glossy or matt surface.
Product information
Technical properties
Resistance
| Durability | 7 Year(s) | Applies for vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most |
| Maximum shrinkage |
Maximum shrinkage along: 0.2 mm Maximum shrinkage across : 0 mm |
Bonded to steel | no measurable shrinkage in transverse direction, average value, FINAT TM 12 |
| Elongation at break |
Minimum elongation at break along: 130 % Minimum elongation at break across: 150 % |
EN ISO 527, average value |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527, average value |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/23 °C no change, DIN 50021 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 90 °C |
Bonded to aluminum, short-term load | (short-term, max. 24h, at +100° C), no change |
Adhesive properties
| Adhesive power | 16 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, UV printing, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner |
Liner: RaidAir paper PE-coated on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material | Polymer PVC film |
| Adhesive |
Density adhesive: 0.07 kg/m³ Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.07 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll | |
|---|---|---|
| Standard width | 1050 mm | only available in glossy white |
| 1600 mm | only available in glossy white | |
| 1370 mm | ||
| 1520 mm | ||
| Standard length | 50 m |
