Technical data sheet - English (EN)
PDF, 91.40kB, 2 Pages
ORAJET® 3106SG
Caravan Film
Calendered high-performance polymer PVC film with excellent adherence properties on difficult substrates. Available in white silk-gloss surface.
Product information
Technical properties
Resistance
| Durability | 7 Year(s) | with vertical outdoor weathering, central European normal climate, unprinted | Applies for vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 1 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most oils |
| Maximum shrinkage | Unsupported type | Unsupported type | |
| Elongation at break |
Minimum elongation at break along: 130 % Minimum elongation at break across: 150 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium, after 100 h/35 °C | no change, EN ISO 9227 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
Bonded to aluminum, short-term load |
Adhesive properties
| Adhesive power | 28 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | with high initial and high final adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 4 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material |
Thickness front material: 0.1 mm Front material: Polymer PVC film |
| Adhesive |
Thickness adhesive: 1 mm Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.1 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| Standard length | 50 m |
