Technical data sheet - English (EN)
PDF, 81.57kB, 2 Pages
ORAJET® 3105HT
White polymer PVC film with a glossy surface for longterm advertising measures, markings and decorations in outdoor areas. Particularly suitable for applications on surfaces that are difficult to apply.
Product information
Technical properties
Resistance
| Durability | 5 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 1 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most oils |
| Maximum shrinkage | Unsupported type | Unsupported type | |
| Elongation at break |
Minimum elongation at break along: 130 % Minimum elongation at break across: 150 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | DIN 50021, after 100 h/ 23 °C no change |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 28 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | with high initial and high final adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 4 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material | Polymer PVC film |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.1 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| 1520 mm | |
| Standard length | 50 m |
