ORACAL® 7510RA
Fluorescent Premium Cast
Cast PVC film with a high degree of attention thanks to its intense lighting effect in all daylight conditions. Especially effective at dawn and dusk and other poor visibility conditions. The series ORACAL® 7510 Fluorescent Premium Cast is available in the colours 029: Yellow fluorescent, 037: orange fluorescent, 038: Red orange fluorescent, 039: Red fluorescent, 046: Pink fluorescent, 069: Green fluorescent and 357: Orange red fluorescent. The colour 356 fulfils the requirements of the UNECE R70 for fluorescent material of the red fluorescent colour. The RapidAir technology enables a simple and quick adhesion, whereby the occurrence of blisters and folds in particular for large formatted applications is reduced. Air pockets can be easily smoothed out from under the film.
Available colours
2 Colours
029G
Yellow fluorescent
Glossy
222 250 4 (sRGB)
039G
Red fluorescent
Glossy
247 15 9 (sRGB)
Product information
Technical properties
Resistance
| Durability | Durability :with vertical outdoor exposure, normal Central European climate | |
|---|---|---|
| 3 Year(s) | Yellow fluorescent, unprinted | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50% relative humidity |
| Maximum shrinkage |
Maximum shrinkage along 0.3 mm
Maximum shrinkage across 0 mm |
bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along 120 %
Minimum elongation at break across 120 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 15 N/mm² Minimum tensile strength across: 15 N/mm² |
EN ISO 527 |
| Seawater resistance | no change | after 100h/35°C | adhered to aluminum, DIN EN ISO 9227 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 16 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Screen printing |
|---|---|
| RapidAir technology | Yes |
| Application temperature | Minimum temperature 10 °C |
Product Construction
General
| Thickness | 0.15 mm | Average value, without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 107.18kB, 3 Pages
Product information - English (EN)
PDF, 200.31kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
