Technical data sheet - English (EN)
PDF, 52.16kB, 1 Page
ORATAPE® MT80P
Application Tape
Transparent mounting film on PVC basis, covered, for the transfer of punched or computer-cut lettering and symbols.
Product information
Technical properties
Resistance
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
|---|---|---|
| Elongation at break | Minimum elongation at break along 130 % | DIN EN ISO 527 |
| Tensile strength | 1.27 N/mm² | (EN ISO 527) |
Adhesive properties
| Adhesive power | 2 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Removable |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|
Product Construction
| Liner |
Liner: Glassine paper siliconised on one side Surface weight: 62 g/m² |
|---|---|
| Front material | 0.1 mm |
General
| Thickness | 0.1 mm | Film with adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| 1000 mm | |
| 630 mm | |
| 500 mm | |
| Standard length | 50 m |
Downloads
Technical documents
Product information - English (EN)
PDF, 139.95kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
