Technical data sheet - English (EN)
PDF, 277.10kB, 2 Pages
ORACAL® 7510
Fluorescent Premium Cast
Moulded PVC film with a high degree of attention thanks to its intense lighting effect in all daylight conditions. Especially effective at dawn and dusk and other poor visibility conditions. The series ORACAL® 7510 Fluorescent Premium Cast is available in the colours 029 Yellow fluorescent, 037 Orange fluorescent, 038 Red orange fluorescent, 039 Red fluorescent, 046 Pink fluorescent, 069 Green fluorescent, and 357 Red orange fluorescent.
Available colours
7 Colours
029G
Yellow fluorescent
Glossy
222 250 4 (sRGB)
037G
Orange fluorescent
Glossy
250 126 1 (sRGB)
038G
Red-Orange fluorescent
Glossy
248 63 13 (sRGB)
357G
Orange-Red fluorescent
Glossy
248 22 8 (sRGB)
039G
Red fluorescent
Glossy
247 15 9 (sRGB)
046G
Pink fluorescent
Glossy
244 7 124 (sRGB)
069G
Green fluorescent
Glossy
58 207 0 (sRGB)
Product information
Technical properties
Resistance
| Durability | Durability (general note):with professional processing, with vertical outdoor weathering, central European normal climate | |
|---|---|---|
| 2 Year(s) | all colours, unprinted | |
| 3 Year(s) | Yellow fluorescent, unprinted | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity * |
| Maximum shrinkage |
Maximum shrinkage along: 0.3 mm Maximum shrinkage across : 0 mm |
bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 15 MPa Minimum tensile strength across: 15 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | DIN 50021, after 100 h/ 23 °C no change |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 105 °C |
normal climate of Central Europe; |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Screen printing |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Adhesive | Solvent-polyacrylate |
|---|
General
| Thickness | 0.15 mm | Average value, without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 44.05kB, 2 Pages
Product information - English (EN)
PDF, 140.52kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
