Technical data sheet - English (EN)
PDF, 112.35kB, 2 Pages
ORACAL® 631
Exhibition Cal
Soft PVC film with matt surface
Available colours
60 Colours
000M
Transparent
Matt
213 213 219 (sRGB)
010M
White
Matt
231 234 238 (sRGB)
020M
Golden yellow
Matt
252 166 0 (sRGB)
019M
Signal yellow
Matt
235 174 0 (sRGB)
021M
Yellow
Matt
254 198 0 (sRGB)
022M
Light yellow
Matt
242 203 0 (sRGB)
025M
Brimstone yellow
Matt
241 225 14 (sRGB)
030M
Dark red
Matt
145 8 20 (sRGB)
031M
Red
Matt
175 0 11 (sRGB)
032M
Light red
Matt
199 12 0 (sRGB)
047M
Orange red
Matt
211 48 0 (sRGB)
034M
Orange
Matt
221 68 0 (sRGB)
036M
Light orange
Matt
236 102 0 (sRGB)
035M
Pastel orange
Matt
255 109 0 (sRGB)
040M
Violet
Matt
93 43 104 (sRGB)
043M
Lavender
Matt
120 95 162 (sRGB)
042M
Lilac
Matt
186 148 188 (sRGB)
041M
Pink
Matt
195 40 106 (sRGB)
045M
Soft pink
Matt
239 135 184 (sRGB)
429M
Carnation pink
Matt
242 182 193 (sRGB)
050M
Dark blue
Matt
28 47 94 (sRGB)
049M
King blue
Matt
23 43 121 (sRGB)
086M
Brilliant blue
Matt
27 47 170 (sRGB)
057M
Traffic blue
Matt
0 65 142 (sRGB)
051M
Gentian blue
Matt
0 69 131 (sRGB)
098M
Gentian
Matt
0 79 159 (sRGB)
052M
Azure blue
Matt
0 94 173 (sRGB)
053M
Light blue
Matt
0 136 195 (sRGB)
056M
Ice blue
Matt
67 162 211 (sRGB)
172M
Powder blue
Matt
169 201 234 (sRGB)
066M
Turquoise blue
Matt
0 131 142 (sRGB)
054M
Turquoise
Matt
0 155 151 (sRGB)
055M
Mint
Matt
95 206 183 (sRGB)
060M
Dark green
Matt
0 60 36 (sRGB)
061M
Green
Matt
0 122 77 (sRGB)
062M
Light green
Matt
0 137 58 (sRGB)
064M
Yellow green
Matt
35 155 17 (sRGB)
063M
Lime-tree green
Matt
106 167 47 (sRGB)
493M
Olive
Matt
137 143 61 (sRGB)
495M
Key lime pie
Matt
188 228 152 (sRGB)
622M
Pastel green
Matt
201 222 96 (sRGB)
818M
Saffron yellow
Matt
220 190 155 (sRGB)
800M
Nougat brown
Matt
85 51 28 (sRGB)
801M
Clay brown
Matt
142 93 59 (sRGB)
083M
Nut brown
Matt
175 89 30 (sRGB)
817M
Orange brown
Matt
198 182 158 (sRGB)
081M
Light brown
Matt
168 135 90 (sRGB)
816M
Dark beige
Matt
198 182 158 (sRGB)
082M
Beige
Matt
205 192 158 (sRGB)
814M
Ivory
Matt
225 212 176 (sRGB)
070M
Black
Matt
6 6 7 (sRGB)
073M
Dark grey
Matt
75 76 76 (sRGB)
752M
Storm grey
Matt
100 103 109 (sRGB)
071M
Grey
Matt
117 125 124 (sRGB)
074M
Middle grey
Matt
138 143 140 (sRGB)
751M
Warm grey
Matt
188 182 168 (sRGB)
072M
Light grey
Matt
192 195 195 (sRGB)
090M
Silver grey
Matt
111 114 116 (sRGB)
091M
Gold
Matt
121 101 50 (sRGB)
092M
Copper
Matt
105 64 30 (sRGB)
Product information
Technical properties
Resistance
| Durability | 3 Year(s) | with professional processing, with vertical outdoor weathering, central European normal climate |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage |
Maximum shrinkage along: 0.4 mm Maximum shrinkage across : 0 mm |
adhered on aluminium | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 130 % Minimum elongation at break across: 150 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 80 °C |
adhered on aluminium, central European normal climate |
| Water resistance | Tested | adhered on aluminium | after 48 h/23 °C no change |
Adhesive properties
| Adhesive power | 7 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Removable |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|
Product Construction
| Front material |
Thickness front material: 0.08 mm Front material: Soft PVC Film |
|---|---|
| Adhesive | Polyacrylate |
General
| Thickness | 0.08 mm | without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| 1000 mm | |
| 630 mm | |
| 500 mm | |
| Standard length | 50 m |
