Technical data sheet - English (EN)
PDF, 56.83kB, 2 Pages
ORACAL® 383
Ultraleaf Cast
Self-adhesive, cast and metallised film with a three-dimensional embossed structure. The alkyd resin surface gives Ultraleaf Cast excellent weather resistance and lasting form stability. Through the use of a permanent acrylate adhesive, excellent adhesion on a multitude of surfaces for long-term outdoor applications is achieved. Available in chrome and brushed chrome finishes.
Available colours
2 Colours
001G
Chrome
Glossy
003G
Gold gloss
Glossy
Product information
Technical properties
Resistance
| Durability | Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.452 | |
|---|---|---|
| 5 Year(s) | with professional processing, with vertical outdoor weathering, central European normal climate | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium, |
| Maximum shrinkage |
Maximum shrinkage along 0.25 mm
Maximum shrinkage across 0.25 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_conditon.id.452.393f406f | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.452.393f406f |
| Elongation at break |
Minimum elongation at break along 35 %
Minimum elongation at break across 35 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 17 N/mm² Minimum tensile strength across: 17 N/mm² |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 16 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|
Product Construction
| Liner |
Liner: One-sided siliconized kraft paper Surface weight: 137 g/m² |
|---|---|
| Front material | 0.085 mm |
General
| Thickness | 0.085 mm | Average value, without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1220 mm |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 107.18kB, 3 Pages
Product information - English (EN)
PDF, 139.47kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
