Technical data sheet - English (EN)
PDF, 107.54kB, 1 Page
ORACAL® 351
Polyester Film
Metallised polyester film with excellent form stability and good durability. Developed specifically for the processing on computer-controlled cutting systems. Available in the colours chrome, matt chrome, brushed chrome, bright gold on both sides and rose gold.
Available colours
5 Colours
001G
Chrome
Glossy
002M
Matt chrome
Matt
907BR
Chrome brushed
Brushed
911G
Gloss gold on both sides
Glossy
931G
Rose gold
Glossy
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | 0.5 % household cleaning agent at room temperature and at 65 °C |
|---|---|---|
| Durability | 2 Year(s) | with professional processing, with vertical outdoor weathering, central European normal climate |
| 1 Year(s) | bright gold on both sides, for professional processing, applies for vertical outdoor weathering and central European normal climate | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium |
| Maximum shrinkage |
Maximum shrinkage along: 0.1 mm Maximum shrinkage across : 0 mm |
bonded to steel |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 80 % |
Average value, EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 200 MPa Minimum tensile strength across: 260 MPa |
Average value, EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 120 °C |
adhered on aluminium, central European normal climate |
| Water resistance | Tested | adhered on aluminium | after 100 h no change |
Adhesive properties
| Adhesive power | 12 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 8 °C |
|---|
Product Construction
| Liner |
Liner: Special silicone cardboard coated on one side Surface weight: 137 g/m² |
|---|---|
| Front material | Metallised polyester film |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.023 mm | Chrome, matte chrome, bright gold on both sides. Average value, without protective liner and adhesive |
|---|---|---|
| 0.05 mm | Chrome brushed, pink gold. Average value, without protective liner and adhesive |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| 1000 mm | |
| 630 mm | |
| 500 mm | |
| 378 mm | |
| Standard length | 50 m |
