Technical data sheet - English (EN)
PDF, 166.28kB, 2 Pages
ORALITE® 5200
Economy Grade
ORALITE® 5200 Economy Grade is a multifunctional reflective film specifically designed for directional signs and reflective advertising where a low level of reflectivity is sufficient. Offering a durability of 3 years, it is ideal for short-term outdoor applications. The film is available in 6 colours and is also available as ORALITE® 5200RA version with RapidAir® technology for easy, bubble free application.
- Versatile: Perfect for signage and reflective advertising in short-term outdoor applications
- Robust and smooth surface: Offers high scratch and impact resistance as well as very good printability
- Reliable adhesion: Equipped with solvent polyacrylate adhesive for reliable bonding
- Optional RapidAir® technology: ORALITE® 5200RA ensures bubble-free bonding and saves time during application
- 6 colour options: Offers creative flexibility for different applications
Available colours
6 Colours
010
White
020
Yellow
035
Orange
030
Red
060
Green
050
Blue
Product information
Technical properties
Resistance
| Durability | 3 Year(s) | with professional processing, with vertical outdoor weathering, central European normal climate, no guarantee for non-vertical application |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 82 °C |
bonded to aluminum, normal Central European climate, no guarantee for non-vertical application |
Adhesive properties
| Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Inkjet printing with solvent inks, Inkjet printing with latex inks, Inkjet printing with UV inks, Screen printing |
|---|---|
| Suitable substrate | Aluminium, Galvanised sheet steel |
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner |
Liner: Silicone cardboard PE coated on both sides Surface weight: 145 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.1 mm | Average value, without protective paper |
|---|
Reflective Characteristics
| Reflective Technology | Glass bead |
|---|---|
| Reflectivity Compliance | Reflective film structure: Design A |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 610 mm |
| 1235 mm | |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 182.78kB, 6 Pages
Product information - English (EN)
PDF, 140.81kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
Catalogue
Traffic Signs & Construction Zones - English (EN)
PDF, 3.13MB, 24 Pages
Digital Printing Materials - English (EN)
PDF, 1.77MB, 11 Pages
Printing Materials - English (EN)
PDF, 2.21MB, 11 Pages
