ORAJET® 3164
Soft PVC film in transparent and white with a glossy and matt surface for brilliant and colour intensive short and medium-term outdoor advertising..
Product information
Technical properties
Resistance
| Durability | 4 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage | Unsupported type | Unsupported type | |
| Elongation at break |
Minimum elongation at break along: 130 % Minimum elongation at break across: 150 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 80 °C |
adhered on aluminium | normal climate of Central Europe; |
| Water resistance | Tested | adhered on aluminium | after 48 h/23 °C no change |
Adhesive properties
| Adhesive power | 16 N/25 mm | after 24 h, on stainless steel | FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner |
Liner: Silicone cardboard coated on one side Surface weight: 135 g/m² |
|---|---|
| Front material |
Thickness front material: 0.1 mm Front material: Soft PVC Film |
| Adhesive | Polyacrylate |
General
| Thickness | 0.1 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 760 mm |
| 1000 mm | |
| 1050 mm | |
| 1260 mm | |
| 1370 mm | |
| 1520 mm | |
| 1600 mm | |
| 2000 mm | |
| Standard length | 50 m |
