Technical data sheet - English (EN)
PDF, 84.42kB, 1 Page
ORAFLEX® 11406
Edge Sealing Tape
The one-sided adhesive tape consists of a PVC carrier, that is coated on one side with a natural rubber adhesive. The adhesive shows good immediate and permanent adhesion on different surfaces.
Product information
Technical properties
Resistance
| Shelf Life | 1 Year(s) | in original packaging at 20 °C and 50 % humidity |
|---|---|---|
| Resistance to solvents and chemicals | Weak acids, Salts and alkalis | |
| Tensile strength | 4 MPa | EN ISO 527 |
| Temperature resistance | Maximum temperature 70 °C | 1 h, central European normal climate |
Adhesive properties
| Adhesive power | 3 N/25 mm | after 1 min, FINAT TM 1, on stainless steel |
|---|---|---|
| 4 N/25 mm | after 20 min, FINAT TM 1, on stainless steel | |
| 5 N/25 mm | after 24 h, FINAT TM 1, on stainless steel |
Processing
| Application temperature | Maximum temperature 15 °C |
|---|
Product Construction
| Adhesive covered side | Natural rubber | |
|---|---|---|
| Adhesive open side | Natural rubber | |
| Carrier |
Colour carrier: White Carrier: PVC film |
0.03 mm |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 25 mm |
| Standard length | 66 m |
Downloads
Technical documents
Product information - English (EN)
PDF, 141.39kB, 1 Page
Shelf Life - English (EN)
PDF, 163.28kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
