ORABOND® UHB03110G
Acrylic Foam Tape
The ORABOND® UHB03110G adhesive tape consists of an acrylate adhesive which was developed for adhesions and mounting applications that are exposed to extremely high shear and temperature stresses. Thanks to the visco-elastic properties of the UHB® adhesive, stresses resulting from different thermal expansion coefficients of the adhesive substrates can be equalised. This also allows for an excellent surface wetting, which leads to extremely high adhesive forces. The adhesive tape offers excellent UV resistance.
Product information
Technical properties
Resistance
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
|---|---|---|
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 150 °C |
short-term up to 200 °C |
Adhesive properties
| Dynamic shear strength | 0.62 N/mm² | after 24 h, on stainless steel | based on ASTM D1002 |
|---|---|---|
| Adhesive tensile strength (T-pull) | 0.77 N/mm² | on anodised aluminium, after 24 h | based on ASTM D897 |
| Adhesive power | 51 N/25 mm | after 24 h, on stainless steel | based on ASTM D3330 |
Processing
| Application temperature | Minimum temperature 15 °C |
|---|
Product Construction
| Liner |
Liner: PE film Colour cover material: Red |
|
|---|---|---|
| Adhesive covered side | Acrylate adhesive "UHB03" | |
| Adhesive open side | Acrylate adhesive "UHB03" |
Liner
Dimensions
| Format | Roll, Cut | |
|---|---|---|
| Cutting roll width | 12 mm | |
| 19 mm | ||
| 25 mm | ||
| Standard width | 800 mm | |
| Standard length | 33 m |
