ORALITE® 5900
High Intensity Prismatic Grade
ORALITE® 5900 High Intensity Prismatic Grade is a high-quality, prismatic reflective film (class: RA2, design C, thickness: 0.23 mm) that has been specially developed for traffic signs, guidance systems and warning markings. With its innovative honeycomb structure, it ensures excellent visibility, even in poor lighting conditions. Thanks to its excellent corrosion and solvent resistance, it offers a long service life of up to 10 years. The permanent solvent polyacrylate adhesive guarantees reliable and durable adhesion to various surfaces. The film is available in 9 colours and is ideal for long-lasting road traffic applications.
- Highly reflective quality: Reflective film (class: RA2, design C, thickness: 0.23 mm) especially for traffic signs, guidance systems and warning markings
- Striking honeycomb structure with choice of colours: Clear visibility thanks to the honeycomb structure, available in 9 colours
- Durability: 10-year warranty when installed correctly
- Excellent adhesion: With permanent solvent polyacrylate adhesive for reliable and durable bonding
- Resistant: Exceptional corrosion and solvent resistance for demanding applications
Available colours
9 Colours
010
White
020
Yellow
030
Red
035
Orange
050
Blue
060
Green
080
Brown
029
Yellow-Green fluorescent
037
Yellow fluorescent
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on aluminium | 0.5 % household cleaning agent) at room temperature and 65 °C |
|---|---|---|
| Durability | 10 Year(s) | unprinted, with professional processing, with vertical outdoor weathering, central European normal climate |
| Shelf Life | 1 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Temperature resistance |
Minimum temperature: -56 °C Maximum temperature: 82 °C |
adhered on aluminium |
Adhesive properties
| Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|
Processing
| Recommended printing procedure | Screen printing, Digital print with UV-curing inks |
|---|---|
| Suitable substrate | Aluminium, Galvanised sheet steel |
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner | One-sided silicon-coated PP film |
|---|---|
| Front material | Acrylic film |
| Adhesive |
Colour adhesive: White Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.23 mm | Average value, without protective liner and adhesive |
|---|
Reflective Characteristics
| Reflective Technology | Prismatic |
|---|---|
| Reflectivity Compliance | Reflective film structure: Aufbau C (mikroprismatisch) |
| Reflectivity classes: RA2 |
Dimensions
| Format | Roll | |
|---|---|---|
| Standard width | 1235 mm | |
| 610 mm | and special widths | |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 176.27kB, 6 Pages
Product information - English (EN)
PDF, 193.20kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
Catalogue
Traffic Signs & Construction Zones - English (EN)
PDF, 4.13MB, 40 Pages
ORALITE® UV Traffic Sign Printers - English (EN)
PDF, 861.92kB, 8 Pages
