ORAJET® 3959
Petrol Resistant
Premium cast PVC film in white with glossy surface, petrol-resistant
Product information
Technical properties
Resistance
| Durability | 8 Year(s) | with vertical outdoor weathering, central European normal climate |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Fuels, Oils, Weak acids, Salts and alkalis | in combination with petrol-resistant laminating film ORAGUARD® 3959 and 72 h after adhesion on steel substrate | largely resistant to overflowing fuels (petrol, diesel) and oils, weak acids, salts and alkalis |
| Maximum shrinkage |
Maximum shrinkage along: 0.1 mm Maximum shrinkage across : 0 mm |
Bonded to steel | no measurable shrinkage in transverse direction, FINAT TM 14, average value |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/23 °C no change, DIN 50021 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
adhered on aluminium, central European normal climate |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material |
Front material: Cast PVC film Manufacturing process: Moulded |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.055 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| Standard length | 50 m |
