ORAGUARD^® 259
Laminating Film

Transparent Premium Cast PVC film with glossy surface and with a highly effective UV protection, petrol-resistant

Product information

Technical properties

Durability	Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.535
	8 Year(s)
Shelf Life	2 Year(s)	* in original packaging, at 20 °C and 50 % relative humidity
Resistance to solvents and chemicals	Fuels, Weak acids, Salts and alkalis, Water, Isopropyl alcohol, Washing suds (0.5 % household cleaner)	in combination with petrol-resistant digital print film ORAJET® 3959 and 72 h after adhesion on steel substrate largely consistent
Maximum shrinkage	Maximum shrinkage along 0.1 mm Maximum shrinkage across 0.1 mm	product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_conditon.id.535.c424abd9 \| Max 0.1 mm in running direction Bonded to steel, no measurable shrinkage in transverse direction
Elongation at break	Minimum elongation at break along 50 % Minimum elongation at break across 50 %	DIN EN ISO 527
Tensile strength	Minimum tensile strength along: 19 N/mm² Minimum tensile strength across: 19 N/mm²	EN ISO 527
Temperature resistance	Minimum temperature: -40 °C Maximum temperature: 60 °C	adhered on aluminium

Adhesive power	14 N/25 mm	after 24 h, on stainless steel, average value \| FINAT TM 1
Adhesive	Permanent

Processing

Application temperature	Minimum temperature 10 °C

Product Construction

Liner	Liner: One-sided siliconized kraft paper Surface weight: 90 g/m²

Thickness	0.055 mm	without protective liner and adhesive, average value

Dimensions

PDF, 36.92kB, 1 Page

PDF, 140.80kB, 1 Page

Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
