ORAJET® 3951
Premium cast PVC film, available in white and transparent with glossy surface.
Product information
Technical properties
Resistance
| Durability | 10 Year(s) | Applies for vertical outdoor weathering, central European normal climate, white; unprinted |
|---|---|---|
| 8 Year(s) | Applies for vertical outdoor weathering, central European normal climate, white; unprinted | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage |
Maximum shrinkage along: 0.1 mm Maximum shrinkage across : 0 mm |
Bonded to steel | no measurable shrinkage in transverse direction, FINAT TM 14, average value |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
EN ISO 527, average value |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527, average value |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/35 °C no change (both unlaminated, as well as laminated with ORAGUARD® 290) |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 100 °C |
adhered on aluminium | Short-term load |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.055 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1050 mm |
| 1370 mm | |
| 1520 mm | |
| Standard length | 50 m |
