ORAJET® 3161DT
Digital Printing Film
The soft PVC film is available in glossy or matt white and in a transparent version with a glossy surface, for brilliant and colour-intensive short and medium-term outdoor advertising. Notably, the film's good processing properties, even at low temperatures, are a particularly noteworthy feature.
Product information
Technical properties
Resistance
| Durability | Durability :with vertical outdoor exposure, normal Central European climate | |
|---|---|---|
| 4 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50% relative humidity |
| Maximum shrinkage |
Maximum shrinkage along 0.4 mm
Maximum shrinkage across 0 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_conditon.id.558.889f02a7 | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.558.889f02a7 |
| Elongation at break |
Minimum elongation at break along 130 %
Minimum elongation at break across 150 % |
product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_lengthwise_note.id.558.1d706476 |
| Tensile strength |
Minimum tensile strength along: 19 N/mm² Minimum tensile strength across: 19 N/mm² |
DIN EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
Short-term exposure up to 80 °C |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature -5 °C |
|---|
Product Construction
| Liner |
Liner: One-sided siliconized kraft paper Surface weight: 137 g/m² |
|---|---|
| Front material |
Thickness front material: 0.1 mm Front material: Soft PVC Film |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1520 mm |
| 1370 mm | |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 196.70kB, 3 Pages
Product information - English (EN)
PDF, 200.46kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
Catalogue
Digital Printing Materials - English (EN)
PDF, 1.77MB, 11 Pages
