ORAGUARD® PPF2815MF+
Paint Protection Film
Surface-functionalised polyurethane film, transparent, matt with excellent UV resistance and self-healing surface. The surface has a low surface energy (lotus effect) and a particularly high resistance to chemicals. The migration of dirt is prevented effectively in the film through the surface coating - meaning that the 2815MF+ is resistant to yellowing.
Available colours
3 Colours
000M
Transparent
Matt
218 217 224 (sRGB)
010M
White
Matt
240 241 241 (sRGB)
070M
Black
Matt
28 28 28 (sRGB)
Product information
Technical properties
Resistance
| Durability | Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.540 | |
|---|---|---|
| 10 Year(s) | ||
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Water, Sulphuric acid (10 %), Hydrochloric acid (10 %), Bird droppings (pancreatin), Tree resin, Fuels, Motor oil, Isopropyl alcohol | product.properties.technical_attributes.durability.chemical_resistance_group.chemical_resistance_condtion.id.540 |
| Maximum shrinkage |
Maximum shrinkage along 0.2 mm
Maximum shrinkage across 0.2 mm |
Bonded to steel | FINAT TM 14, average value |
| Elongation at break |
Minimum elongation at break along 300 %
Minimum elongation at break across 300 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 29 N/mm² Minimum tensile strength across: 29 N/mm² |
EN ISO 527 |
| Stone chip resistance | Passed | To SAE J400 2.4L gravel |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 100 °C |
Adhesive properties
| Adhesive power | 17 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 10 °C | |
|---|---|---|
| Proposed application technology | Wet application | Wet application procedure with ORAFOL Application Gel |
Product Construction
| Liner | PET film, single-side silicone coated |
|---|---|
| Front material |
Thickness front material: 0.16 mm Front material: Polyurethane |
General
| Thickness | 0.16 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll | |
|---|---|---|
| Standard width | 200 mm | only in 15 m length |
| 1520 mm | ||
| 1830 mm | only in transparent | |
| Standard length | 50 m | transparent only |
| 25 m | only for coloured films, including white and black | |
| 15 m | transparent only |
