ORACAL® CA Series
Window films for cars
One-layered carbon car window film with ideal thickness and different colour tone options. ORACAL® CA window films are produced with advanced technology. The colour does not fade and the films are not reflective. Heat-blocking performance of this product is higher than conventional window films. ORACAL® CA offers an easy application if the right methods and devices are used. The ORACAL® logo is printed on the wipeable film surface of the car window films and can very easily be wiped off with isopropyl alcohol.
Product information
Technical properties
Resistance
| Durability | Durability :product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.2993 | |
|---|---|---|
| 7 Year(s) | ||
| Shelf Life | 7 Year(s) | product.properties.technical_attributes.durability.storage_lifetime_group.storage_lifetime_condition.id.2993 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 100 °C |
Adhesive properties
| Adhesive | Permanent |
|---|---|
| Repositionability | Repositionable |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|
Product Construction
| Liner | Polyester film, siliconised on one side |
|---|---|
| Front material |
Thickness front material: 0.038 mm Front material: PET film |
| Adhesive |
Colour adhesive: Transparent Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.038 mm |
|---|
Sun protection properties
| Glare reduction | 88 % |
|---|---|
| IR rejection | 31 % |
| Reflecting (visible light, outdoors) | 5.1 % |
| Reflecting (visible light, indoors) | 5 % |
| Solar energy absorption | 57.9 % |
| Solar energy reflection | 5.8 % |
| Solar energy transmission | 36.3 % |
| Total solar energy rejection | 48.6 % |
| Transmission (visible light) | 11 % |
| UV rejection | 99 % |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1525 mm |
| Standard length | 30 m |
