ORACAL® Basic Series
Multi-layer metallised car window film with ideal thickness and various colour options The films of the ORACAL® Basic series are produced with advanced technology. The colour does not fade and the heat blocking performance of this product is higher than standard window films. ORACAL® Basic window films allow for an easy application if the correct methods and devices are used. The car window films have the ORACAL® logo printed on the film surface that can be easily wiped off with isopropyl alcohol.
Product information
Technical properties
Resistance
| Durability | 5 Year(s) |
|---|---|
| Shelf Life | 5 Year(s) |
Adhesive properties
| Repositionability | Repositionable |
|---|
Product Construction
| Liner |
Liner: Transparent polyester silicone-coated on one side Surface weight: 0.25 g/m² |
|---|---|
| Adhesive |
Colour adhesive: Transparent Adhesive: Acrylic copolymer |
General
| Thickness | 0.038 mm |
|---|
Sun protection properties
| Glare reduction | 88 % |
|---|---|
| IR rejection | 37 % |
| Reflecting (visible light, outdoors) | 7.2 % |
| Reflecting (visible light, indoors) | 4.9 % |
| Solar energy absorption | 59.7 % |
| Solar energy reflection | 7.9 % |
| Solar energy transmission | 32.4 % |
| Total solar energy rejection | 52 % |
| Transmission (visible light) | 10.8 % |
| UV rejection | 99 % |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1525 mm |
| Standard length | 30 m |
