ORACAL® 961RA
Caravan Film Premium Cast
Moulded premium PVC film, with excellent adhesive properties on difficult substrates, in glossy white, black, silver grey, yolk yellow (further colours on request). The RapidAir technology allows for easy and quick, blister-free adhesion, in particular for large format adhesive objects. Air pockets can be easily removed from under the film.
Product information
Technical properties
Resistance
| Durability | 10 Year(s) | Black, white, applies for vertical outdoor weathering, central European normal climate | Maximum durability with professional processing and proper care and use |
|---|---|---|
| 8 Year(s) | coloured, applies for vertical outdoor weathering, central European normal climate | Maximum durability with professional processing and proper care and use | |
| 6 Year(s) | metallic: silver grey, applies for vertical outdoor weathering and central European normal climate | Maximum durability with professional processing and proper care and use | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, after 72 h on aluminium | against most |
| Maximum shrinkage |
Maximum shrinkage along: 0.2 mm Maximum shrinkage across : 0.2 mm |
Bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 150 % Minimum elongation at break across: 150 % |
Average value, metallic: 120%, DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 21 MPa Minimum tensile strength across: 21 MPa |
Average value, metallic: 19 MPa, EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/35 °C no change, EN ISO 9228 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 120 °C |
adhered on aluminium | no change, short-term exposure |
Adhesive properties
| Adhesive power | 20 N/25 mm | Average value, after 24 h stainless steel | FINAT TM 1 |
|---|
Processing
| RapidAir technology | Yes | The RapidAir technology allows for an easy and quick, blister-free adhesion, in particular for large format adhesive objects. Air pockets can be remove easily. |
|---|
Product Construction
| Liner |
Liner: RaidAir paper PE-coated on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material |
Front material: Premium PVC film Manufacturing process: Moulded |
| Adhesive | Modified solvent polyacrylate |
General
| Thickness | 0.055 mm | Average value without protective paper and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| Standard length | 50 m |
