Technical data sheet - English (EN)
PDF, 276.55kB, 1 Page
ORACAL® 8810
Frosted Glass Cast
Cast high-performance PVC films for the high-quality glass decoration with very good weathering and UV resistance. The reduced surface gloss and the roughly structured surface prevent unwanted reflections.
Available colours
5 Colours
090M
Silver grey
Matt
091M
Gold
Matt
085M
Rosé
Matt
055M
Mint
Matt
056M
Pale blue
Matt
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on glass, 8 h in detergent solution with 0.5 % household detergent at room temperature and at 65 °C |
|---|---|---|
| Durability | Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.480 | |
| 7 Year(s) | ||
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Weak acids, Salts and alkalis, Isopropyl alcohol, Washing suds (0.5 % household cleaner) | at room temperature 72 h after adhesion on aluminium |
| Maximum shrinkage |
Maximum shrinkage along 0.1 mm
Maximum shrinkage across 0.1 mm |
adhered on glass | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.480.ea643986 |
| Elongation at break |
Minimum elongation at break along 40 %
Minimum elongation at break across 40 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 9 N/mm² Minimum tensile strength across: 9 N/mm² |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
bonded to glass, normal Central European climate |
| Water resistance | Tested | at 23 °C, bonded on aluminium | after 100 h no change |
Adhesive properties
| Adhesive power | 16 N/25 mm | adhered on glass, after 24 h, stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| 16 N/25 mm | adhered on acrylic glass, after 24 h, on stainless steel | Average value, FINAT TM 1 | |
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|---|
| Proposed application technology | Wet application |
Product Construction
| Liner | Polyester film, siliconised on one side |
|---|
General
| Thickness | 0.08 mm | Average value, without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| 1000 mm | |
| 630 mm | |
| 500 mm | |
| 378 mm | |
| Standard length | 50 m |
| 25 m |
