ORALUX® 9300
Luminescent Cast

Three-layer cast, light yellow, cadmium-free high performance PVC film with glossy surface. Fulfils the requirements of DIN 67510. The afterglow effect is characterised by a particularly high initial brightness, immediately after switching off the stimulating light source. The excitation can be carried out as often as required without reducing the luminous properties of the film. Does not contain radioactive materials.

Product information

Technical properties

Resistance

Durability Durability :product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.616
5 Year(s)
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Maximum shrinkage Maximum shrinkage along 0.3 mm
Maximum shrinkage across 0.3 mm 		Bonded to steel | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.616.adf224d6
Elongation at break Minimum elongation at break along 100 %
Minimum elongation at break across 100 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 12 N/mm²
Minimum tensile strength across: 10 N/mm² 		DIN EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 60 °C 		Short-term exposure up to 80 °C

Adhesive properties

Adhesive power 18 N/25 mm after 24 h, on stainless steel | FINAT TM 1, average value
Adhesive Permanent
Processing
Recommended printing procedure Screen printing
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: PE-coated paper on both sides, siliconised on one side
Surface weight: 143 g/m²

General

Dimensions
Format Roll
Standard width 1000 mm
1260 mm
Standard length 50 m
25 m
10 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
