ORALITE® 6910
Brilliant Grade
ORALITE® 6910 Brilliant Grade Premium is a highly reflective film, class RA3B, design C for vertical traffic signs. It is designed for adhesion to smooth metal surfaces such as aluminum and galvanized steel. The film offers outstanding reflection, is available in 10 colours, including 3 fluorescent colours, and boasts a durability of up to 12 years. It complies with the EN 12899-1 and DIN 67520-4 standards and is CE certified.
- Certified safety: CE certification including declaration of performance according to EN 12899-1
- Excellent visibility: High reflectivity for optimal visibility both day and night (RA3B, design C)
- Robust durability: Weather and UV resistant with up to 12 years of durability
- Versatile printing options: Compatible with screen printing (ORALITE® 5018) and UV digital printing (ORALITE® 5019i )
Available colours
9 Colours
010
White
020
Yellow
030
Red
035
Orange
050
Blue
060
Green
029
Yellow-Green fluorescent
037
Yellow fluorescent
038
Orange fluorescent
Product information
Technical properties
Resistance
| Durability | general note:with professional processing and vertical outdoor weathering | |
|---|---|---|
| 12 Year(s) | unprinted | |
| 10 | Yellow-Green fluorescent, Yellow fluorescent | |
| 3 | Orange fluorescent | |
| Shelf Life | 1 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Temperature resistance |
Minimum temperature: -56 °C Maximum temperature: 82 °C |
adhered on aluminium |
Adhesive properties
| Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, film tear |
|---|---|---|
| Adhesive | Permanent | Metallic substrates like aluminium or galvanised sheet steel |
Processing
| Application temperature | Minimum temperature 10 °C |
|---|
Product Construction
General
| Thickness | 0.345 mm | Average, without protective liner, standard colours |
|---|---|---|
| 0.385 mm | Average, without protective liner, fluorescent colours |
| Front material | Acrylic film |
|---|---|
| Adhesive |
Colour adhesive: White Adhesive: Solvent-polyacrylate |
Reflective Characteristics
| Reflective Technology | Prismatic |
|---|---|
| Reflectivity Compliance | Reflective film structure: Aufbau C (mikroprismatisch) |
| Reflectivity classes: RA3B |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1235 mm |
| 610 mm | |
| Standard length | 50 m |
