ORALITE® 5931
Prismatic Construction Grade
ORALITE® 5931 Prismatic Construction Grade is a highly reflective reflective film (class RA2, design C) specially developed for temporary traffic guidance and construction site protection. It is available in five colours, optionally with red or black print, and offers reliable adhesion thanks to its permanent solvent polyacrylate adhesive. The film is ideal for polyolefin substrates and is available both on a roll and cut to size. With a durability of up to 5 years, it impresses with its longevity and functionality.
- Highly reflective: Reflective film (class RA2, structure C) for maximum visibility by day and night
- Reliable application: Ideal for construction site safety and temporary traffic signage, even on polyolefin substrates
- Choice of colours: Available in 4 colours, optionally with black or red print
- Durable and strong adhesion: Up to 5 years durability with permanent solvent polyacrylate adhesive for a secure hold
- Flexible availability: Available in rolls or cut to size
Available colours
4 Colours
010
White / Red
020
Yellow / Red
029
Yellow-Green fluorescent / Red
038
Orange fluorescent / Black
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on aluminium | 8 h in detergent solution (0.5 % household cleaner) at room temperature and 65 °C |
|---|---|---|
| Durability | 5 Year(s) | unprinted, with professional processing, with vertical outdoor weathering, central European normal climate |
| Shelf Life | 1 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 82 °C |
adhered on aluminium |
Adhesive properties
| Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Suitable substrate | Polyolefin substrates, Aluminium, Galvanised sheet steel |
|---|
Product Construction
| Liner | One-sided silicon-coated PP film |
|---|---|
| Front material | Polymer PVC film |
| Adhesive |
Colour adhesive: Transparent Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.48 mm | Average value, without protective liner and adhesive |
|---|
Reflective Characteristics
| Reflective Technology | Prismatic |
|---|---|
| Reflectivity Compliance | Reflective film structure: Aufbau C (mikroprismatisch) |
| Reflectivity classes: RA2 |
Dimensions
| Format | Roll, Sheets | |
|---|---|---|
| Standard width | 246 mm | |
| Standard length | 50 m | |
| Standard dimensions sheets | 1000 mm X 246 mm |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 162.37kB, 2 Pages
Product information - English (EN)
PDF, 200.92kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
Catalogue
Traffic Signs & Construction Zones - English (EN)
PDF, 4.13MB, 40 Pages
