ORALITE® 5860
High Intensity Construction Grade
ORALITE® 5860 High Intensity Construction Grade is a high quality reflective film for temporary traffic signs, guidance devices and warning markings. With a honeycomb structure and outstanding corrosion and solvent resistance, this film ensures long-lasting visibility and safety under various conditions.
- High-intensity reflection: Reflective film for excellent visibility by day and night
- Wide range of applications: Ideal for temporary traffic signs, traffic guidance systems and information boards
- Striking honeycomb structure with choice of colours: Clear visibility thanks to the honeycomb structure available in 6 colours
- Longterm durability: With a shelf life of 5 years, this film offers lasting performance when applied professionally
- Robust and durable: Maximum corrosion and solvent resistance for longterm outdoor use
Available colours
6 Colours
010
White
020
Yellow
035
Orange
030
Red
060
Green
050
Blue
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on aluminium | 8 h in detergent solution (0.5 % household cleaner) at room temperature and 65 °C |
|---|---|---|
| Durability | 5 Year(s) | unprinted, with professional processing, with vertical outdoor weathering, central European normal climate |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Mineral oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | with professional bonding |
| Temperature resistance |
Minimum temperature: -56 °C Maximum temperature: 82 °C |
adhered on aluminium | DIN 50021, after 100 h/ 23 °C no change |
Adhesive properties
| Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Screen printing |
|---|---|
| Suitable substrate | Aluminium, Galvanised sheet steel |
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner | One-sided silicon-coated PP film |
|---|---|
| Front material | Acrylic film |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.21 mm | Average value, without protective liner and adhesive |
|---|
Reflective Characteristics
| Reflective Technology | Glass bead |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1235 mm |
| 920 mm | |
| 760 mm | |
| 610 mm | |
| Standard length | 50 m |
