ORALITE® 5700
Engineer Grade Premium

ORALITE® 5700 Engineer Grade Premium is a high-quality reflective film (RA1, design A) that is characterised by its excellent reflectivity and high durability. With a thickness of 0.130 mm and a durability of up to 7 years, this film is ideal for applications on traffic signs, guidance and warning markings and information signs. It offers excellent corrosion and solvent resistance, ensuring reliable results in a wide range of conditions.
  • Reflective film (class: RA1, design A, thickness: 0.130 mm): Optimum reflectivity for clear visibility at night
  • Wide range of applications: Ideal for traffic signs, guidance and warning markings as well as information signs
  • Colour options: Available in 8 colours for versatile design options
  • Durability of up to 7 years: For permanent applications and reliable results
  • Maximum corrosion and solvent resistance: Particularly resistant to environmental influences and chemical substances

Product information

Technical properties

Resistance

Durability 7
Shelf Life 2 Year(s)
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 80 °C 		adhered to aluminium, under standard Central European climatic conditions
Processing
Recommended printing procedure Screen printing, UV printing, Eco-solvent printing
Product Construction
Front material Alkyd resin
Reflective Characteristics
Reflective Technology Glass bead
Reflectivity Compliance Reflective film structure: Design A (embedded glass beads)
Reflectivity classes: RA1
Dimensions
Format Roll
Standard width 610 mm
760 mm
920 mm
1235 mm
1520 mm
Standard length 50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
