ORALITE® reflective films of the series 5421 COMMERCIAL FLEET MARKING GRADE are flexible, weatherproof, self-adhesive, retroreflective films with excellent corrosion and solvent resistance. The smooth surface of the ORALITE® reflective films series 5421 COMMERCIAL FLEET MARKING GRADE enables excellent printability. The reflection system of the ORALITE® reflective films of the series 5421 COMMERCIAL FLEETMARKING consists of catadioptric glass beads which are embedded in a translucent plastic layer (corresponds to requirement class RA1, structure A, previously type I). Reflection values and daytime direct-light colours comply with the international specifications for reflective materials of this class, e.g. EN 12899-1 (Europe), DIN 67520 and DIN 6171 (Germany), BS 873: Part 6 (Great Britain), NFP 98-520 (France), SN 640878 (Switzerland), ASTM D 4956 (US), JIS Z 9117 (Japan).
Durability | 4 Year(s) | with professional processing, with vertical outdoor weathering, central European normal climate |
---|---|---|
Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
---|---|---|
Adhesive | Removable |
Application temperature | Minimum temperature 10 °C |
---|
Liner | Silicone cardboard PE coated on both sides |
---|---|
Adhesive | Solvent-polyacrylate |
Thickness | 0.09 mm | Average value, without protective liner and adhesive |
---|
Reflective Technology | Glass bead |
---|---|
Reflectivity Compliance | Reflective film structure: Design A |
Reflectivity classes: RA1 |
Format | Roll, Cut | |
---|---|---|
Cutting roll width | 282 mm | x 9 m |
141 mm | x 9 m (set of left + right) | |
Standard width | 282 mm | |
141 mm | ||
Standard length | 50 m |
