ORAJET® 3691
Digital Printing Film
Blended polymer PVC film with matt surface and surface coating for better printability.
Product information
Technical properties
Resistance
| Durability | Durability (general note):with professional processing, with vertical outdoor weathering, central European normal climate | |
|---|---|---|
| 5 Year(s) | unprinted | |
| 2 Year(s) | printed | |
| 3 Year(s) | printed and laminated with ORAGUARD® 236 | |
| Shelf Life | 2 Year(s) | in original packaging (with side holders) vertical storage, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Weak acids, Salts and alkalis, Isopropyl alcohol, Washing suds (0.5 % household cleaner) | product.properties.technical_attributes.durability.chemical_resistance_group.chemical_resistance_condtion.id.599 |
| Maximum shrinkage |
Maximum shrinkage along 0.4 mm
Maximum shrinkage across 0 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_conditon.id.599.597985c9 | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.599.597985c9 |
| Elongation at break |
Minimum elongation at break along 130 %
Minimum elongation at break across 150 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 19 N/mm² Minimum tensile strength across: 19 N/mm² |
EN ISO 527 |
| Seawater resistance | no change | product.properties.technical_attributes.durability.seawater_resistance_group.seawater_resistance_condition.id.599 | product.properties.technical_attributes.durability.seawater_resistance_group.seawater_resistance_note.id.599 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
Bonded to aluminum, short-term load |
Adhesive properties
| Removability | Removable | Within 3 years | can be removed from most surfaces residue-free |
|---|---|---|
| Adhesive power | 8 N/25 mm | after 24 h stainless steel | FINAT TM 1, average value, |
Processing
| Recommended printing procedure | Inkjet printing with UV inks |
|---|---|
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner |
Liner: PE-coated paper on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Front material |
Thickness front material: 0.07 mm Front material: Polypropylene film |
| Adhesive |
Thickness adhesive: 0.024 mm Adhesive: Solvent-polyacrylate |
General
| Thickness | 0.08 mm | Front material + adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1050 mm |
| 1370 mm | |
| Standard length | 50 m |
