ORAJET® 3675
Window Graphics Film
Perforated white, glossy special PVC film with black rear for the use on level, transparent substrates and glass. Printing the film front results in a visible print image, whereby the perforated black rear is translucent. The share of printable areas on the overall area amounts to 50 %. The small hole diameter of 1.5 mm enables a comparatively fine print image.
Product information
Technical properties
Resistance
| Durability | 4 Year(s) | Applies for vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage | Unsupported type | Unsupported type | |
| Elongation at break |
Minimum elongation at break along: 50 % Minimum elongation at break across: 50 % |
EN ISO 527, average value |
| Tensile strength |
Minimum tensile strength along: 5 MPa Minimum tensile strength across: 5 MPa |
EN ISO 527, average value |
| Seawater resistance | Tested | adhered on glass | after 100 h/23 °C no change |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 80 °C |
Bonded to glass, short-term load |
Adhesive properties
| Adhesive power | 12 N/25 mm | after 24 h, glass | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks |
|---|---|
| Application temperature | Minimum temperature 10 °C |
Product Construction
| Liner |
Liner: Non-perforated silicone cardboard coated on one side Surface weight: 135 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.14 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| 1520 mm | |
| Standard length | 50 m |
