ORAJET® 3350
Digital Printing Polyester

Metallised polyester film with excellent form stability and good durability. Surface is equipped with printing varnish. Available in chrome. *on request

Product information

Technical properties

Resistance

Durability Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.576
2 Year(s) with vertical outdoor weathering, central European normal climate; unprinted
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Maximum shrinkage Maximum shrinkage along 0.1 mm
Maximum shrinkage across 0 mm 		bonded to steel | FINAT TM 14
Elongation at break Minimum elongation at break along 125 %
Minimum elongation at break across 80 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 200 N/mm²
Minimum tensile strength across: 260 N/mm² 		EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 100 °C

Adhesive properties

Adhesive power 12 N/25 mm after 24 h, on stainless steel | FINAT TM 1
Adhesive Permanent
Processing
Recommended printing procedure Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks A maximum temperature of 100 °C may not be exceeded when printing with latex inks.
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: PE-coated paper on both sides, siliconised on one side
Surface weight: 143 g/m²
Front material Thickness front material: 0.05 mm
Front material: Metallised polyester film

General

Thickness 0.05 mm without protective liner and adhesive, average value
Dimensions
Format Roll
Standard width 1370 mm
Standard length 50 m
