ORAJET® 3301F
Digital Printing Polyester

Metallised, glossy polyester film with excellent form stability and good durability. The surface is equipped with special printing varnish. Available in chrome and brushed chrome finishes. *on request

Product information

Technical properties

Resistance

Durability 2 Year(s) with vertical outdoor weathering, central European normal climate
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Maximum shrinkage Maximum shrinkage along: 0.2 mm
Maximum shrinkage across : 0 mm 		bonded to steel | no measurable shrinkage in transverse direction, FINAT TM 14
Elongation at break Minimum elongation at break along: 125 %
Minimum elongation at break across: 80 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 200 MPa
Minimum tensile strength across: 260 MPa 		EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 120 °C 		Bonded to aluminum

Adhesive properties

Adhesive power 23 N/25 mm stainless steel, after 1 min | FINAT-TM1
25 N/25 mm stainless steel, after 24 h | FINAT-TM1
8 N/25 mm HDPE, after 1 min | FINAT-TM1
10 N/25 mm HDPE, after 24 h | FINAT-TM1
Adhesive Permanent with high initial adhesion and high final adhesion
Processing
Recommended printing procedure Inkjet printing with solvent-based inks, UV printing, Inkjet printing with latex inks
Application temperature Minimum temperature 8 °C
Product Construction
Liner Liner: Polyester film, siliconised on one side
Thickness cover material: 1 kg/m³
Front material Thickness front material: 0.05 mm
Front material: Metallised polyester film
Adhesive Solvent-polyacrylate

General

Thickness 0.05 mm without protective liner and adhesive
Dimensions
Format Roll
Standard width 1370 mm
Standard length 50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
