Technical data sheet - English (EN)
PDF, 138.73kB, 1 Page
| Durability | Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.574 | |
|---|---|---|
| 2 Year(s) | with vertical outdoor weathering, central European normal climate | |
| Shelf Life | 2 Year(s) | product.properties.technical_attributes.durability.storage_lifetime_group.storage_lifetime_condition.id.574 |
| Maximum shrinkage |
Maximum shrinkage along 0.4 mm
Maximum shrinkage across 0 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_conditon.id.574.6378d140 | product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_lengthwise_note.id.574.6378d140 |
| Elongation at break |
Minimum elongation at break along 180 %
Minimum elongation at break across 200 % |
product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_lengthwise_note.id.574.36889352 |
| Tensile strength |
Minimum tensile strength along: 30 N/mm² Minimum tensile strength across: 28 N/mm² |
product.properties.technical_attributes.durability.tear_strength_group.tear_strength_lengthwise_note.id.574 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 60 °C |
product.properties.technical_attributes.durability.temperature_resistance_block.temperature_resistance_condition.id.574.ca9eb03d |
| Adhesive power | 6 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Removable |
| Application temperature | Minimum temperature 10 °C |
|---|
| Liner |
Liner: One-sided siliconized kraft paper Surface weight: 137 g/m² |
|---|---|
| Front material | 0.15 mm |
| Format | Roll |
|---|---|
| Standard width | 1370 mm |
| 1520 mm | |
| Standard length | 50 m |
PDF, 138.73kB, 1 Page
PDF, 57.51kB, 2 Pages
PDF, 142.32kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
PDF, 671.00kB, 3 Pages
PDF, 1.77MB, 11 Pages
Polymeric PVC laminating film with highly effective UV protection for outdoor applications.
