ORACAL® 970RA+ ProSlide™
Premium Wrapping Cast

Multi-layered, high performance PVC film cast according to optimized technology that has been developed for vehicle wrapping without additional lamination. High-gloss surface as well as many colours also available in matt. The RapidAir structure of the adhesive enables simple and blister-free adhesion. Air pockets can be easily smoothed out from under the film. The ProSlide Technology (RA+ ProSlide) makes attachment quick and easy thanks to the improved ability to reposition the new product. This way projects can be realised in even less time. ORACAL® 970RA+ ProSlide is particularly suitable for the adhesion on painted substrates, even on uneven and curved surfaces as well as in beads. In adhered state the material can be removed with suitable aids.

Product information

Technical properties

Resistance

Durability Durability :with vertical outdoor exposure, normal Central European climate
12 Year(s) Black, white
10 Year(s) coloured
5 Year(s) metallic
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50% relative humidity
Resistance to solvents and chemicals Mineral oils, Greases, Fuels, Weak acids, Salts and alkalis, Isopropyl alcohol, Washing suds (0.5 % household cleaner) At room temperature
Maximum shrinkage Maximum shrinkage along 0.1 mm
Maximum shrinkage across 0.1 mm 		bonded to steel | FINAT TM 14
Elongation at break Minimum elongation at break along 150 %
Minimum elongation at break across 150 % 		DIN EN ISO 527
Minimum elongation at break along 120 %
Minimum elongation at break across 120 % 		product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_lengthwise_note.id.2633.92c2d8ed
Tensile strength Minimum tensile strength along: 21 N/mm²
Minimum tensile strength across: 21 N/mm² 		EN ISO 527
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 60 °C 		adhered on aluminium, central European normal climate

Adhesive properties

Adhesive power 12 N/25 mm after 24 h, on stainless steel | Average value, FINAT TM 1
Adhesive Permanent
Repositionability Repositionable
Processing
RapidAir technology Yes
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: PE-coated RapidAir and ProSlide paper on both sides, siliconised on one side
Surface weight: 158 g/m²

General

Thickness 0.11 mm Average value, without protective liner and adhesive
Dimensions
Standard width 1520 mm
Standard length 25 m
50 m
