ORACAL® 952
Premium Cast

Moulded premium PVC film with excellent form stability and optimum processing properties. The special adhesive allows for adhesion on painted substrates. Surface glossy in the colours white and transparent. Further colours on request.

Product information

Technical properties

Resistance

Durability 10 Year(s) with vertical outdoor weathering central European normal climate; unprinted
Shelf Life 2 Year(s) at 20 °C and 50 % relative humidity | in original packaging
Resistance to solvents and chemicals Oils, Weak acids, Salts and alkalis, Greases, Aliphatic solvents, Fuels at room temperature, 72 h after adhesion on aluminium | resistant against most
Maximum shrinkage Unsupported type | Unsupported type
Elongation at break Minimum elongation at break along: 120 %
Minimum elongation at break across: 120 % 		product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_transverse_note.id.485.f6196e52
Tensile strength Minimum tensile strength along: 19 MPa
Minimum tensile strength across: 19 MPa 		EN ISO 527
Seawater resistance Tested adhered on aluminium | after 100 h/ 23 °C no change, DIN 50022
Temperature resistance Minimum temperature: -50 °C
Maximum temperature: 110 °C 		product.properties.technical_attributes.durability.temperature_resistance_block.temperature_resistance_condition.id.485.4ade8e25

Adhesive properties

Adhesive power 18 N/25 mm after 24 h, on stainless steel | Average value, FINAT TM 1
Processing
Recommended printing procedure Screen printing special colours are required for UV offset printing and flexographic printing
Application temperature Minimum temperature 8 °C
Product Construction
Liner Liner: PE-coated paper on both sides, siliconised on one side
Surface weight: 143 g/m²
Front material Front material: Premium PVC film
Manufacturing process: Moulded
Adhesive Colour adhesive: Transparent
Adhesive: Solvent-polyacrylate

General

Thickness 0.07 mm Average value without protective paper and adhesive
Dimensions
Format Roll, Sheets
Standard width 1000 mm
1260 mm
1400 mm
Standard length 50 m
Standard dimensions sheets 700 mm X 1000 mm
500 mm X 700 mm
1000 mm X 700 mm

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
