ORACAL® 8830
Diffuser Premium Cast
Moulded, matt-white diffuser film with 30 % light transmission. The film improves the light distribution and allows for even illumination of illuminated signs and illuminated advertising. The reduced surface gloss prevents unwanted reflections.
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on acrylic glass, 8 h in mild detergent solution (0.5 % household detergent) at room temperature and 65 °C |
|---|---|---|
| Durability | Durability (general note):The durability of the film depends to a large extent on the climatic conditions and the effect of light. | |
| 10 Year(s) | with vertical outdoor weathering, central European normal climate | |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Maximum shrinkage |
Maximum shrinkage along: 0.1 mm Maximum shrinkage across : 0 mm |
product.properties.technical_attributes.durability.maximum_shrinkage_block.maximum_shrinkage_transverse_conditon.id.481.67ffe902 |
| Elongation at break |
Minimum elongation at break along: 120 % Minimum elongation at break across: 120 % |
product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_transverse_note.id.481.8340d3ec |
| Tensile strength |
Minimum tensile strength along: 21 MPa Minimum tensile strength across: 21 MPa |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 80 °C |
product.properties.technical_attributes.durability.temperature_resistance_block.temperature_resistance_condition.id.481.16232d1b |
Adhesive properties
| Adhesive power | 18 N/25 mm | adhered on glass, after 24 h | Average value, FINAT TM 1 |
|---|---|---|
| 16 N/25 mm | adhered on acrylic glass, after 24 h | Average value, FINAT TM 1 | |
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 8 °C |
|---|
Product Construction
| Adhesive | Solvent-polyacrylate |
|---|
General
| Thickness | 0.055 mm | Average value, without protective paper and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1260 mm |
| Standard length | 50 m |
| 25 m |
