Technical data sheet - English (EN)
PDF, 1.37MB, 2 Pages
ORACAL® 851
Sparkling Glitter Metallic Cast Film
Sparkling Glitter Metallic Cast PVC film for plotter applications with optimum cutting and processing properties. Specifically developed for labelling, markings and decorations. The surface has a high-gloss finish. Available in 18 fascinating high-gloss glitter metallic colours, including 986 Crystal Clear Sparkle transparent, which can be laminated onto the surface of any ORACAL 631, 641, 651, 751 or 951 standard plotter film colour to create a vibrant glitter metallic effect
Available colours
18 Colours
985G
Ghostly white
Glossy
987G
Intense silver
Glossy
995G
Sweet almond
Glossy
994G
Bridal pink lace
Glossy
977G
Sinister orange
Glossy
989G
Golden knight
Glossy
988G
Obsidian silver
Glossy
990G
Golden naval
Glossy
981G
Dynamic blue
Glossy
991G
Frosted lagoon
Glossy
982G
Envy green
Glossy
992G
Chiffon mint
Glossy
993G
Golden bell
Glossy
983G
Daffodil yellow
Glossy
984G
Explosive red
Glossy
976G
Electric orange
Glossy
996G
Blooming coral
Glossy
986G
Crystal clear
Glossy
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on aluminium |
|---|---|---|
| Durability | 5 Year(s) | with professional processing and proper care and use, applies for vertical outdoor weathering and central European normal climate |
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature 72 h after adhesion on aluminium |
| Maximum shrinkage |
Maximum shrinkage along: 0.2 mm Maximum shrinkage across : 0.2 mm |
bonded to steel | FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 125 % Minimum elongation at break across: 125 % |
DIN EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 20 MPa Minimum tensile strength across: 20 MPa |
EN ISO 527 |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 120 °C |
bonded to aluminum, short-term load |
| Water resistance | Tested | at 23 °C | after 100 h no change |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, on stainless steel | FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent |
Processing
| Application temperature | Minimum temperature 8 °C |
|---|
Product Construction
| Front material |
Front material: PVC Manufacturing process: Moulded |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.1 mm | coloured, average value, without protective liner and adhesive |
|---|---|---|
| 0.075 mm | Crystal Clear, average value, without protective liner and adhesive |
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1220 mm |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 107.18kB, 3 Pages
Product information - English (EN)
PDF, 140.38kB, 1 Page
Conditions for maintenance and usage - English (EN)
PDF, 159.81kB, 2 Pages
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
