Technical data sheet - English (EN)
PDF, 144.34kB, 2 Pages
ORACAL® 7710RA
Fluorescent Premium Cast Plus
Specially developed for emergency vehicles, moulded premium PVC film with a high degree of attention thanks to its intensive lighting effect in all daylight conditions. Especially effective at dawn and dusk and other poor visibility conditions. The series ORACAL® 7710RA Fluorescent Premium Cast Plus is available in the colours 029 Yellow fluorescent and 039 Red fluorescent. The RapidAir technology enables a simple and quick adhesion, whereby the occurrence of blisters and folds in particular for large formatted applications is reduced. Air pockets can be easily smoothed out from under the film. The special adhesive allows adhesion on painted substrates, even if they are uneven. With strongly curved surfaces as well as in beads and over rivets, the film has to be cut and bonded overlapping. In adhered state the material can be removed with suitable aids.
Available colours
2 Colours
029G
Yellow fluorescent
Glossy
222 250 4 (sRGB)
039G
Red fluorescent
Glossy
247 15 9 (sRGB)
Product information
Technical properties
Resistance
| Resistance to cleaning agents | No change | adhered on aluminium |
|---|---|---|
| Durability | Durability (general note):The real durability and durability to be expected depend in particular on ambient conditions, amongst other also after the pre-treatment of the substrate and regular care. | |
| 4 Year(s) | central European normal climate, with professional processing and proper care and use, vertical outdoor weathering | |
| Shelf Life | 2 Year(s) | in original packaging upright, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium |
| Maximum shrinkage |
Maximum shrinkage along: 0.15 mm Maximum shrinkage across : 0.15 mm |
bonded to steel | Average value, FINAT TM 14 |
| Elongation at break |
Minimum elongation at break along: 150 % Minimum elongation at break across: 150 % |
Average value, EN ISO 527 |
| Tensile strength |
Minimum tensile strength along: 18 MPa Minimum tensile strength across: 18 MPa |
Average value, EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | EN ISO 9227, after 100 h/35 °C no change |
| Temperature resistance |
Minimum temperature: -50 °C Maximum temperature: 120 °C |
adhered on aluminium | Short-term load |
| Water resistance | Tested | at 23 °C, bonded on aluminium | after 100 h no change |
Adhesive properties
| Adhesive power | 16 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
| Repositionability | Repositionable | repositionable with permanent end adhesion |
Processing
| RapidAir technology | Yes |
|---|---|
| Application temperature | Minimum temperature 15 °C |
Product Construction
| Liner |
Liner: RaidAir paper PE-coated on both sides, siliconised on one side Surface weight: 143 g/m² |
|---|---|
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.17 mm | Average value, without protective liner and adhesive |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1520 mm |
| Standard length | 50 m |
| 25 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 107.18kB, 3 Pages
Product information - English (EN)
PDF, 140.03kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
