ORACAL^® 620
Print Vinyl

Very supple soft PVC film. Available in different colours, surface glossy or matt.

Product information

Technical properties

Durability	Durability :with vertical outdoor exposure, normal Central European climate
	3 Year(s)	unprinted, with professional processing, with vertical outdoor weathering, central European normal climate
Shelf Life	2 Year(s)	in original packaging, at 20 °C and 50% relative humidity
Maximum shrinkage	Maximum shrinkage along 0.4 mm Maximum shrinkage across 0 mm	bonded to steel \| FINAT TM 14
Elongation at break	Minimum elongation at break along 130 % Minimum elongation at break across 150 %	DIN EN ISO 527
Tensile strength	Minimum tensile strength along: 19 N/mm² Minimum tensile strength across: 19 N/mm²	EN ISO 527
Temperature resistance	Minimum temperature: -40 °C Maximum temperature: 60 °C	adhered on aluminium, central European normal climate
Water resistance	Tested	adhered on aluminium \| after 48 h/23 °C no change

Removability	Removable	can be removed residue-free from most surfaces within 2 years
Adhesive power	6 N/25 mm	after 24 h, on stainless steel \| Average value, FINAT TM 1
Adhesive	Removable

Processing

Recommended printing procedure	Screen printing, UV offset printing, Flexographic printing	Special inks are required for flexographic and UV offset print.
Application temperature	Minimum temperature 10 °C

Product Construction

Liner	Liner: One-sided siliconized kraft paper Surface weight: 137 g/m²
Front material	Thickness front material: 0.08 mm Front material: Soft PVC Film

Thickness	0.08 mm	Average value, without protective liner and adhesive

Dimensions

PDF

PDF, 44.05kB, 2 Pages

PDF, 193.69kB, 1 Page

Our safety data sheets / product information consider the state of the SVHC list of 2026-02-04.
