ORACAL® 552
High Performance Vinyl

High-performance PVC film which ensures excellent light-fastness and weather resistance to the highest degree. This film is available in white and transparent with glossy surface.

Product information

Technical properties

Resistance

Durability Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.454
7 Year(s) unprinted, with professional processing, with vertical outdoor weathering, central European normal climate
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Resistance to solvents and chemicals Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis at room temperature, 72 h after adhesion on aluminium
Maximum shrinkage Maximum shrinkage along 0.2 mm
Maximum shrinkage across 0 mm 		bonded to steel | FINAT TM 14
FINAT TM 14
Elongation at break Minimum elongation at break along 130 %
Minimum elongation at break across 150 % 		DIN EN ISO 527
Tensile strength Minimum tensile strength along: 19 N/mm²
Minimum tensile strength across: 19 N/mm² 		EN ISO 527
Seawater resistance no change adhered on aluminium | DIN 50021, after 100 h/ 23 °C no change
Temperature resistance Minimum temperature: -60 °C
Maximum temperature: 60 °C 		bonded to aluminum, short-term, max. 24h, Central European normal climate

Adhesive properties

Adhesive power 18 N/25 mm after 24 h, on stainless steel | Average value, FINAT TM 1
Adhesive Permanent
Processing
Recommended printing procedure Screen printing, Flexographic printing, UV offset printing Special inks are required for UV offset printing and flexographic printing
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: PE-coated paper on both sides, siliconised on one side
Surface weight: 143 g/m²
Front material Thickness front material: 0.07 mm
Front material: Polymer PVC film

General

Thickness 0.07 mm Average value, without protective liner and adhesive
Dimensions
Format Roll, Sheets
Standard width 1000 mm
1260 mm
1400 mm
Standard length 50 m
Standard dimensions sheets 500 mm X 700 mm
700 mm X 1000 mm
1000 mm X 1400 mm
