ORACAL® 970RA
Premium Wrapping Cast

Multi-layered, high performance PVC film moulded according to optimized technology that has been developed for vehicle wrapping without additional lamination. High-gloss surface as well as many colours, also available in matt, in addition black in super matt. Developed specifically for vehicle wrapping. The RapidAir technology allows for an easy and quick, blister-free adhesion, in particular for large format adhesive objects. Air pockets can be easily smoothed out from under the film. The special adhesive allows for an adhesion on painted substrates, also on uneven and curved surfaces as well as in beads and over rivets. In adhered state the material can be removed with suitable aids.
  • Premium Wrapping Cast with 108 colors
  • Premium Shift Effect Cast with 16 colors
  • Premium Special Effect Cast with 9 colors
  • Premium Structure Cast

Product information

Technical properties

Resistance

Durability Durability (general note):product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_condition_all.id.493
12 Year(s) black, white, Maximum durability with professional processing and proper care and use applies to vertical outdoor weathering and a normal Central European climate
10 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.1490e148
10 Year(s) coloured, maximum durability with professional processing and proper care and use applies for vertical outdoor weathering and central European normal climate
8 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.36325d81
5 Year(s) metallic, maximum durability with professional processing and proper care and use applies to vertical outdoor weathering and a normal Central European climate
4 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.a17c8ba0
4 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.c183a6b6
3 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.943c0c2b
3 Year(s) Copper, oriental brown metallic, maximum durability with professional processing and proper care and use, applies for vertical outdoor weathering and central European normal climate
2 product.properties.technical_attributes.durability.lifetime_value_group.lifetime_value_block.lifetime_value_condition.id.493.9cf9c5c1
Shelf Life 2 Year(s) in original packaging
Resistance to solvents and chemicals Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis at room temperature, 72 h after adhesion on aluminium
Maximum shrinkage Maximum shrinkage along 0.1 mm
Maximum shrinkage across 0 mm 		bonded to steel | FINAT TM 14
Elongation at break Minimum elongation at break along 150 %
Minimum elongation at break across 150 % 		DIN EN ISO 527
Minimum elongation at break along 120 %
Minimum elongation at break across 120 % 		metallics, DIN EN ISO 527
Minimum elongation at break along 35 %
Minimum elongation at break across 35 % 		product.properties.technical_attributes.durability.elongation_at_break_block.elongation_at_break_lengthwise_note.id.493.bb00e87c
Tensile strength Minimum tensile strength along: 21 N/mm²
Minimum tensile strength across: 21 N/mm² 		EN ISO 527
Seawater resistance no change adhered on aluminium | EN ISO 9227, after 100 h/35 °C no change
Temperature resistance Minimum temperature: -40 °C
Maximum temperature: 60 °C 		Short-term load, bonded to aluminum

Adhesive properties

Removability Removable with suitable aids
Adhesive power 16 N/25 mm after 24 h stainless steel | FINAT TM 1, average value
Adhesive Permanent
Repositionability Repositionable
Processing
RapidAir technology Yes with large-format adhesive objects | Developed specifically for vehicle wrapping
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: RaidAir paper PE-coated on both sides, siliconised on one side
Surface weight: 143 g/m²

General

Thickness 0.11 mm without protective liner and adhesive
Dimensions
Format Roll
Standard width 1520 mm
Standard length 25 m
50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-05-25.
